Toshiba Tosvert VF-S15 Function Manual

E6582051
- 50 -
6.5.24.
fd07
(Output TB Status) (VF-S15/MB1)
bit TB Name Function (Parameter) 0 1
0 RY-RC Output terminal function selection 1A (
f130
)OFF ON
1 OUT Output TB Function select 2A (
f131
) OFF ON
2 FL Output TB Function select 3 (
f132
) OFF ON
3 - 15 (Undefined) - - -
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.
6.5.25. fd07 (Output TB Status) (VF-AS3)
bit TB Name Function (Parameter) 0 1
0 FP
f130:
Terminal FP function 1 OFF ON
1 (Undefined) - - -
2
FL
f132:
Terminal FL function OFF ON
3
R1
f133:
Terminal R1 function 1 OFF ON
4
R2
f134:
Terminal R2 function OFF ON
5
DQ11
f159:
Terminal DQ11 function OFF ON
6
DQ12
f160:
Terminal DQ12 function OFF ON
7
R4
f161:
Terminal R4 function OFF ON
8
R5
f162:
Terminal R5 function OFF ON
9
R6
f163:
Terminal R6 function OFF ON
10
R4(B)
a201:
Terminal R4 (B) function OFF ON
11
R5(B)
a202:
Terminal R5 (B) function OFF ON
12
R6(B)
a203:
Terminal R6 (B) function OFF ON
13 to 15 (Undefined) - - -
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
