Toshiba Tosvert VF-S15 Function Manual

E6582051
- 65 -
Example in this product is shown below.
This product supports only Basic Device ID.
Response format: Unit ID = 251 (Communication module)
Byte Meaning Example value
0 Function Code = 2Bh 0x2B
1 Type of MEI 0x0E
2 Read Device ID code 0x01: Basic
3 Conformity Level 0x02
4 More Follows 0: No more Object
5 Next Object Id 0
6 Number Of Objects 3 for Basic.
6 for Regular or Extended
7 Obj 0 Id  Vendor Name 0
8 Obj 0 length 7
9-15 Obj 0 value “TOSHIBA”
16 Obj 1 Id  ProductCode 1
17 Obj 1 length 7
18-24 Obj 1 value “PNE001Z”
25 Obj 2 Id  Version 2
26 Obj 2 length 4
27-30 Obj 2 value “0201”
Exception response format:
Byte Meaning
0 Function Code = 0xAB
1
Exception Code
01: Illegal Function
02: Illegal Data Address
03: Illegal Data Value

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
