Toshiba TS2100 - Fabricating Extension I;O Signal Cable; Attaching and Detaching Extension I;O Signal Cable

INTERFACE MANUAL
• Electric rating
Electric rating Cautions
Rated voltage DC24 V
Rated current 100 mA (max.)
Rated current of the built-in power supply is 3
A. (The total current of the hand, external
output and extension output modules should
be 3 A or less.)
If the current which exceeds the rated output
current is supplied, the output device may be
damaged or the printed board may be burnt.
To avoid this, be sure to use within the rated
output current.
NEVER use an external power supply.
Otherwise, the system will malfunction.
8.3 Fabricating Extension I/O Signal Cable
When fabricating the extension I/O signal cable, see Para. 4.9.
8.4 Attaching and Detaching Extension I/O Signal Cable
For attaching and detaching the extension I/O signal cable, see Para. 4.10.
