120 Ethernet module User’s Manual
Chapter 6 Socket Interface Communication
6
Start
Read the station status
7EFFH on DPRAM
(word address)
Run mode ?
Is the result of ANDing 1000H
is 1000H ?
Issue the operating mode control request
(Standby)
Issue the reset request
Issue the parameter setting request
Issue the operating mode control request
(Run)
Read the station status
Requested operating
mode ?
End
Y
Y
N
N
