4.4.4 Error Status List
The status right after the completion of the USEND_T or URCV_T execution is displayed
at STATUS. If the error status is 16#EC**(-50**), it means that the error was detected on
the CPU module side. If the error status is 16#EB**, it means that the error was detected
on the EN311 side.
Table 4-2 Error Status Description
STATUS Name Description
0 Normal
completion
-5001
(16#EC77)
Parameter error • Occurs if a slot number other than 03xxH is specified.
• Occurs if a command number not existed in the USEND_T
function block is specified.
• Occurs if a value other than 1 to 8 is specified for the socket
identifier.
• Occurs if an incorrect parameter is specified in a RAS infor-
mation readout request.
-5002
(16#EC76)
Transmission
complete
timeout
• Occurs if an S3 internal timer times out before the EN311
reply while one of the following command is issued.
UDP open, UDP send, UDP close, TCP send, TCP close
-5051
(16#EC45)
Register
specification
error
• Occurs if a register type not available for local sta-
tion(except D and SW)is specified in a register read
request.
-5071
(16#EC31)
Register
specification
error
• Occurs if a register type not available for remote sta-
tion(except D and SW)is specified in a register write
request.
-5052
(16#EC44)
Response
timeout
• Occurs if a response is not received within the specified
time from a remote station in a register read/write request.
-5054
(16#EC42)
Memory write
protect error
• Occurs if an attempt to store the SW register into the stor-
age area of the local reception data is made in the register
read request.
-5074
(16#EC2E)
Memory write
protect error
• Occurs if an attempt to store the SW register into the stor-
age area of the remote reception data is made in the regis-
ter write request.
-5057
(16#EC3F)
No send
channel (CH)
• Occurs if the EN311 is not installed on the specified slot.
-5058 Reserved
-5059
(16#EC3D)
Incorrect
transmission
word count
• Occurs if either 0 words or 1001 or more words were speci-
fied for a UDC/TCP socket send/receive request.
-5060
(16#EC3C)
Boundary error • Occurs if the area specified as the data storage does not
exist on the S3 in one of the following commands.
RAS information readout, UDP send/receive, TCP send/
receive, register read/write
-5080
(16#EC28)
Boundary error • Occurs if the area specified as the data storage does not
exist on the S3 in the following command(occurs in the
remote station). Register write
-5062
(16#EC3A)
No I/O
response
• Occurs if a command was issued when the S3 cannot
access the EN311.
-5064
(16#EC38)
Send data
capacity
exceeded
• Occurs if a command was repeatedly sent with rapid cycle
to an non-existent remote station.
-5050
(16#EC46)
Error during
reset
• Occurs if another command is issued while a reset has
been requested.
0BxxH
Transmission
error
• Occurs if the EN311 returns an error response.
For more information, see Table 4-3.
