48 Ethernet module User’s Manual
Chapter 4 Preparing for Operation (Software)
4
(3) Reset request from the S controller
It is possible to initiate reset processing from user programs on the S controller. This
section describes the format of the reset processing instruction.
Reset request (using the USEND_T instruction)
The user program requests an initialization to the EN311.
(a) Request command structure and error status
<Request command>
<Error status>
Error status examples
(b) Considerations
• A request can be issued if the EN311 is in run mode, standby mode, or down
mode.
• For TCP open request, TCP receive request, or UDP receive request, if you
use the request with unrestraint wait, issue the reset request after changing
the operation mode to the standby mode.
F0
CMD Destination EN311 module slot number
CMD+1 Command (16#0311)
F0
STATUS =0: Normal completion, ≠ 0: Error status
Error status number Description
-5001(16#EC77) Command type error
-5050(16#EC46) Module error/Initialization in progress
To Next Page
