Chapter 1 Introducing the TNB
6F8C1637
4
1.2 Names and Functions of the Parts
1.2.1 Names of the parts
For TNB21, only the TN-A connector is mounted. TN-B connector is not mounted.
Figure 1-2 Names of the parts of TNB Module (TNB21/TNB22)
TNB21
Optical Fiber Cable
Single Module
State Display
RUN
ERR
SCAN
L-A
State Display
RUN
ERR
SCAN
L-A
L-B
Station Address Setting
STN H
STN L
Action Mode Setting
MODE
Status Display LED (A)
ACT-A
LNK-A
Status Display LED
(B)
ACT-B
LNK-B
TC-net 100
Module Connector (A)
TC-net 100
Module Connector
(
B
)
TNB22
Optical Fiber Cable
Dual Redundant Module
