3.5 Option Functions
Unified Controller Vm series TC-net 100 (TNB) Module Instruction Manual
45
Figure 3-30 shows an example of the self-healthy mode configuration.
Figure 3-32 Configuration example of the self-healthy mode
Remark

If an error occurs in the host controller after an error occurs in the transmission path, the
scan block set for the host controller becomes unhealthy.

If the cable is disconnected in one-unit configuration or two-unit configuration, RAS
information other than scan healthy information cannot be obtained.
PC
Cable
① 1 unit
configuration
② 2 unit
configuration
T
N
B
P
U
B
T
N
B
P
U
B
