Unified Controller Vm series TC-net 100(TNB) Module Manual
67
Figure 7-9 shows the information configuration HUB provides.
This information is available when A system HUB(UTNH21A/UTLH23A)
operates normally.
Word
No.
F 8 7 0
Update
Cycle
Remarks
0 Module Type (0x08) 0 0000011 60s
Install information of the
target HUB (Note 1)
1 HUB healthy counter 1s
2 Reserved
－
3 Reserved
－
4 Optical port 0 Number of received packets (Note 2) 1s Install Stack 0 (A system)
5 Optical port 1 Number of received packets (Note 2) 1s
6 Optical port 2 Number of received packets (Note 2) 1s
7 Optical port 3 Number of received packets (Note 2) 1s
8 Optical port 4 Number of received packets (Note 2) 1s
9 Optical port 5 Number of received packets (Note 2) 1s
10 Optical port 6 Number of received packets (Note 2) 1s
11 Optical port 7 Number of received packets (Note 2) 1s
12 Electrical Port Number of received packets (Note 2) 1s
13 Reserved
－
14 Optical port 0 Number of received packets (Note 2) 1s Install Stack 0 (B system)
15 Optical port 1 Number of received packets (Note 2) 1s
16 Optical port 2 Number of received packets (Note 2) 1s
17 Optical port 3 Number of received packets (Note 2) 1s
18 Optical port 4 Number of received packets (Note 2) 1s
19 Optical port 5 Number of received packets (Note 2) 1s
20 Optical port 6 Number of received packets (Note 2) 1s
21 Optical port 7 Number of received packets (Note 2) 1s
22 Electrical Port Number of received packets (Note 2) 1s
23 Reserved
－
・
・
・
・
・
・
・
・
・
54 Optical port 0 Number of received packets (Note 2) 1s Install Stack 2 (B system)
55 Optical port 1 Number of received packets (Note 2) 1s
56 Optical port 2 Number of received packets (Note 2) 1s
57 Optical port 3 Number of received packets (Note 2) 1s
58 Optical port 4 Number of received packets (Note 2) 1s
59 Optical port 5 Number of received packets (Note 2) 1s
60 Optical port 6 Number of received packets (Note 2) 1s
61 Optical port 7 Number of received packets (Note 2) 1s
62 Electrical Port Number of received packets (Note 2) 1s
63 Reserved
－
(Note 1)
：
Bit location is <0>:A0
、
<1>:B0
、
<2>:A1
、
<3>:B1
、
<4>:A2
、
<5>:B2
A0 is Stack 0 of A system HUB
。
(Note 2)
：
Number of received packets has number of each port normal packets in 16 bits. It transits in
65535→0→1→2...
Figure 7-9 Configuration of RAS information on HUB
