Mounting Flat Panel TV Lift Mount – cont.
3. Using the 4 M8x20 bolts and nuts, mount the horizontal flat panel TV bracket to the lift. Use 1 washer between
the nut and back of the lift mounting plate. Tighten bolts so bracket is secure to lift.
Mounting Screw Installation Back of Lift
4. Once the TV mounting bracket is installed on the lift, the TV is ready to be installed.
