tousek ST 61A - Left Leaf; Right Leaf

- 22 - tousek / EN_ST-61A_08 / 25. 03. 2020
Right leaf Connections and adjustments
G
Motor (Supply: terminals 24/25/26, grounding: 27 - Sensor: terminals 65, 67, 68) Right leaf
 MOTOR ON
 MOTOR OFF.
left motor right motor
INSIDE
If a right operator is not available then
set here to „MOTOR OFF“!
G
Delay right leaf Right leaf
 OPENING DELAY: the right leaf opens after the adjusted delay time.
 CLOSING DELAY: the right leaf closes after the adjusted delay time.
G
Delay time right  2s (factory setting) Right leaf
 0–25s time delay adjustable: indicates the delay time at opening or closing.
ARS response time  0,50 (factory setting) Right leaf
 0,15–0,95 adjustable: indicates the response of the Automatic Rerversal System.
Max. force  70% (factory setting) Right leaf
 20–100% adjustable: indicates the motor force in opening/closing movement.
Soft stop time  5s (factory setting) Right leaf
 0–25s adjustable: indicates the duration of the soft stop time.
Soft start Right leaf
 not active
 active: soft start with SWING X.
The option „soft start“ is only inserted for
SWING X. With SPIN operator soft start is
always active!
Left leaf Connections and adjustments
G
Motor (Supply: terminals 20/21/22, grounding: 23 - Sensor: terminals 65, 66, 68) Left leaf
 MOTOR ON
 MOTOR OFF.
left motor right motor
INSIDE
If a left operator is not available then set
here to „MOTOR OFF“!
G
Delay left leaf Left leaf
 OPENING DELAY: the left leaf opens after the adjusted delay time.
 CLOSING DELAY: the left leaf closes after the adjusted delay time.
G
Delay time left  2s (factory setting) Left leaf
 0–25s time delay adjustable: indicates the delay time at opening or closing.
ARS response time  0,50 (factory setting) Left leaf
 0,15–0,95 adjustable: indicates the response of the Automatic Rerversal System.
Max. force  70% (factory setting) Left leaf
 20–100% adjustable: indicates the motor force in opening/closing movement.
Soft stop time  5s (factory setting) Left leaf
 0–25s adjustable: indicates the duration of the soft stop time.
Soft start Left leaf
 not active
 active: soft start with SWING X.
The option „soft start“ is only inserted for
SWING X. With SPIN operator soft start is
always active!
