TP-Link AP200 User Manual

5
Chapter 1
LED Explanation
Name Status Indication
(Power)
On System initialization completes.
Blinking
System initialization or firmware upgrade is in process. Do not
disconnect or power off the AP device.
Off
Power is off. Please ensure that the power adapter is connected
correctly.
(Wireless 2.4GHz)
On
The wireless 2.4GHz band is working properly (in AP/Multi-SSID/
Repeater/Bridge mode).
Off
The wireless 2.4GHz band is disabled (in AP/Multi-SSID/Repeater/
Bridge mode).
The LED is always off (in Client mode).
(Wireless 5GHz)
On
The wireless 5GHz band is working properly (in AP/Multi-SSID/
Repeater/Bridge mode).
Off
The wireless 5GHz band is disabled (in AP/Multi-SSID/Repeater/
Bridge mode).
The LED is always off (in Client mode).
(LAN)
On A device is connected to the Ethernet port.
Off No device is connected to the Ethernet port.
(WPS)
Slow blinking WPS connection is in process.
On WPS connection is successful. It will turn off after 5 minutes.
Quick blinking WPS connection is failed.
Solid green The signal strength is great (in Repeater/Bridge/Client mode).
Solid orange The signal strength is good (in Repeater/Bridge/Client mode).
Solid red The signal strength is too weak (in Repeater/Bridge/Client mode).
Off
The device is disconnected from the host network (in Repeater/
Bridge/Client mode).
Note:
After a device is successfully added to the network by WPS function, the WPS LED will keep on for about 5 minutes
and then turn off.

TP-Link AP200 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Receiver sensitivity	2.4GHz: 11g 54M: -76dBm@10% PER 11n HT20 MCS7: -73.5dBm@10% PER 11n HT40 MCS7: -71dBm@10% PER 5GHz: 11a 6Mbps:-93dBm@10% PER 11a 54Mbps: -75dBm@10% PER 11ac HT20 MCS8: -67dBm@10% PER 11ac HT40 MCS9: -62.5dBm@10% PER 11ac HT80 MCS9: -59.5dBm@10% PER
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	750 Mbit/s
Maximum data transfer rate (5 GHz)	433 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	1 A
Output voltage	12 V
Antenna type	External
Antenna features	Detachable antenna
Antennas quantity	2
Internal	No
Placement	Table
Certification	CE, FCC, RoHS
Product color	Black
Cables included	LAN (RJ-45)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK, WPS
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX, Linux
Operating altitude	5 - 90 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
