6
Chapter 1
Get to Know About Your Router
The following parts are located on the back panel.
Item Description
WPS
Press for 1 second, and immediately press the WPS button on your client
device to start the WPS process.
LED/ Wi-Fi
Press for 1 second to turn on or off the LED of your router.
Press and hold for about 2 seconds to turn on or off the wireless function of
your router.
Reset
Press and hold this button for about 10 seconds until the Power LED blinks
to reset the router to its factory default settings.
10Gbps WAN/LAN Port For connecting to your modem or the Ethernet outlet.
2.5Gbps WAN/LAN Port For connecting your PC or other wired devices to the router.
1Gbps LAN Port (2-4) For connecting your PC or other wired devices to the router.
USB 3.0 Port For connecting your USB storage devices to the router.
Power Port For connecting the router to a power socket via the provided power adapter.
Power On/Off Press to turn on or off the router.
