TP-Link RE350K - Specifications; Glossary

Appendix 31
Specifications
General
Standards and
Protocols
IEEE 802.3, IEEE 802.3u, IEEE 802.11a, IEEE
802.11n, IEEE 802.11b, IEEE 802.11g, IEEE
802.1x, IEEE 802.11e, IEEE 802.11i, IEEE
802.11ac, TCP/IP, DHCP
Safety & Emission
CE
Ports
One 10/100/1000M Auto-Negotiation LAN RJ45
port
Wireless
Frequency Band
2.4GHz：2.4~2.4835GHz
5GHz：5.15~5.25GHz
Radio Data Rate
2.4GHz：
11n：Up to 450Mbps
11g：54/48/36/24/18/12/9/6Mbps
11b：11/5.5/2/1Mbps
5GHz：
11ac: Up to 1300Mbps
11n: Up to 450Mbps
11a: 54/48/36/24/18/12/9/6Mbps
Security
WEP, WPA-PSK, WPA2-PSK
Physical and Environment
Working Temperature
0℃~40℃ (32℉~104℉)
Working Humidity
10% ~ 90% RH, Non-condensing
Storage Temperature
-40℃~70℃(-40℉~158℉)
Storage Humidity
5% ~ 95% RH, Non-condensing
Glossary
● 802.11b – The 802.11b standard, also known as Wi-Fi, which provides
speeds up to 11 Mbps using direct-sequence spread-spectrum (DSSS)
technology and operating in the unlicensed radio spectrum at 2.4GHz,
and WEP encryption for security.
● 802.11g – The 802.11g specification is for wireless networking at 54
Mbps using direct-sequence spread-spectrum (DSSS) technology, using
OFDM modulation and operating in the unlicensed radio spectrum at
2.4GHz, and backward compatibility with IEEE 802.11b devices, and
WEP encryption for security.
● 802.11n – 802.11n builds upon previous 802.11 standards by adding
MIMO (multiple-input multiple-output). MIMO uses multiple transmitter
and receiver antennas to allow for increased data throughput via spatial
multiplexing and increased range by exploiting the spatial diversity,
perhaps through coding schemes like Alamouti coding. The Enhanced
Wireless Consortium (EWC) was formed to help accelerate the IEEE
802.11n development process and promote a technology specification
