Connect the Extender to the Internet 10
Setup Using a Computer
1 Plug In
Plug in the Range Extender to an electrical wall outlet near your router.
Toggle the Power switch to On and wait until the Power
LED is lit and
solid green.
2 Connect via Wireless
Disconnect the Ethernet (wired) connection from your computer (if any).
Click the
(Wi-Fi) icon on the taskbar and connect to the extender's
network (e.g. TP-LINK_2G_EXT or TP-LINK_5G_EXT). No password is
needed to connect.
3 Log In
Launch a web browser and type: http://tplinkrepeater.net (or
http://192.168.0.254) into the URL field. Enter admin (all lowercase) for
both username and password to log in.
To Next Page
