Introduction 6
Ethernet Port: The 10/100Mbps RJ45 Ethernet port is used to add wireless
connectivity to an Ethernet-enabled device such as Internet TV, DVR, or game
console. Please note that this port cannot be used to connect the extender
directly to the router.
LED Indicators
Name
Status
Indication
Power
Blinking
Green
The extender is initializing or updating
firmware.
Green
The extender is ready for use.
Off
The extender is powered off.
2.4GHz
Blinking
Green
App-Config is initiated.
Green
The extender is connected to the primary
network over 2.4GHz.
Amber
The extender is connected but too far away
from the router.
Off
No connection.
5GHz
Blinking
Green
App-Config is in progress.
Green
The extender is connected to the primary
network over 5GHz.
Amber
The extender is connected but too far away
from the router.
Off
No connection.
