Chapter 1 Get to Know About Your Extender
1. 2. 1. LED Explanation
You can check the extender’s working status by following the LED Explanation table.
Name Status Indication
(RE)
Solid Blue
The extender is connected to the router, and is in a good
location.
Solid Orange
The extender is connected to the router, but is too far away
from the router.
Blinking
The extender is connecting to the network via WPS. This process may
take up to 2 minutes.
Off No active connection.
(2.4GHz)
On
The extender is connected to the 2.4GHz wireless network of
your host router.
Off
No 2.4GHz wireless connection.
(5GHz)
On
The extender is connected to the 5GHz wireless network of
your host router.
Off
No 5GHz wireless connection.
(POWER)
On
The extender is on.
Blinking
The extender is initializing.
Off
The extender is off.
(Ethernet)
On
The Ethernet port is connected.
Off
The Ethernet port is not connected.
1. 2. 2. Port and Button Description
Ports or Buttons Description
Reset Button (Hole)
Press and hold the Reset button until all the LEDs turn on momentarily to reset the
extender to its factory default settings.
RE Button
Press the WPS button on your host router, and immediately press the RE button on
the extender. The RE LED of the extender should change from blinking to solid on,
indicating successful WPS connection.
LED Button To turn all LEDs on or off, press the LED button.
On/Off Button
To turn on or off the extender, press the Power button.
Ethernet Ports
Connect your Ethernet-only device to one of the Ethernet ports to join the Wi-Fi
network.

TP-Link RE580D Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Certification	CE, FCC
Antennas quantity	3
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	1900 Mbit/s
Ethernet LAN (RJ-45) ports	5
Output current	2.5 A
Output voltage	12 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	340 mm
Package height	76 mm
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
