TP-Link TD-W8901G Manual

1
English
Note
1. How can I configure my Router without the Resource CD?
1) Connect your computer to the router with an Ethernet cable
2) Open a web browser and enter the address http://192.168.1.1
3)
The default username and password are both admin
4) If you have changed the username or password and can not remember it,
you will need to restore your Router’s configuration to its factory default
settings then use the default username and password.
2. How do I restore my Router’s configuration to its factory default settings?
Insert the provided Resource
CD into your CD-ROM drive.
Then the Setup Wizard will
automatically pop up on you
r
compute
r
’s screen.
Then a flash video will pop up and
show you how to connect you
r
devices. After that, the Easy
Setup Assistant will start.
Installation
The
p
roduct model shown in this QIG is TD-W8901G, as an exam
p
le.
Troubleshooting
Please select your
product model and click
Start Setup.
Click START, and then follow
the step-by-step instructions
until you complete the
configuration.

TP-Link TD-W8901G Specifications

General

Wireless Speed	Up to 54Mbps
Frequency Band	2.4GHz
ADSL Speed	Downstream: up to 24Mbps, Upstream: up to 3.5Mbps
Wireless Standards	IEEE 802.11g, IEEE 802.11b
ADSL Standards	ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.994.1 (G.hs)
Ports	4 x 10/100Mbps LAN, 1 x RJ-11 ADSL
Antenna	1 x Fixed
Security	64/128-bit WEP, WPA
Protocols	TCP/IP, PPPoE, PPPoA, DHCP
Weight	0.6 lbs (273g)
