TD-W8901N
150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-41
 ADSL Mode: Select the ADSL operation mode which your ADSL connection uses.
 ADSL Type: Select the ADSL operation type which your ADSL connection uses.
4.5 Access Management
Choose “Access Management”, you can see the next submenus:
Figure 4-42
Click any of them, and you will be able to configure the corresponding function.
4.5.1 ACL
Choose “Access Management→ACL”, you can see the next screen (shown in Figure 4-43). You
can specify the client to access the ADSL modem router once setting his IP as a Secure IP
Address through selected applications.
