TP-Link TL-R470T User Manual

-15-
Figure 3-13 WAN Connection Type – PPPoE Connecting
2) If your ISP assigns the IP address automatically, please choose the Dynamic IP connection type
to obtain the parameters for WAN port automatically. The process for obtain the parameter may
take a few minutes as Figure 3-14 shown. If you close the screen during the process, the
configuration will still be continued in the background.
Figure 3-14 WAN Connection Type - Dynamic IP
3) If you choose Static IP, you should enter the detailed IP information provided by your ISP in
Figure 3-15.

TP-Link TL-R470T Specifications

General

Protocols	TCP/IP, PPPoE, DHCP, ICMP, NAT
DHCP	DHCP Server, DHCP Client
Firewall Security	IP and MAC Address Binding
Ports	5 x RJ45 ports
VPN Support	PPTP VPN, L2TP VPN, IPSec VPN
Management	Web-based GUI
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
