Chapter 2 Physical Overview
2.1 Front View
Figure 2-1
Focus Adjustment Ring: Adjust the focus to get a clear image.
Built-in Microphone: Built-in microphone for two-way audio.
2.2 Bottom view
Figure 2-2
Wireless Antenna: For connection of IEEE 802.11b/g wireless network.
Audio In: To support audio in with Microphone for two way audio.
Audio Out: To support audio out with earphones or speakers for two way audio.
Power Connector: For connection of 12V DC input.
Power LED Indicator: Power LED will light up after completing the boot process.
Reset: To successfully restore the camera to factory defaults, please keep the device powered on,
Focus Adjustment Ring
Built-in Microphone
Wireless Antenna
A
udio In
A
udio Out
Power Connecto
r
Power LED Indicato
r
Network Connecto
r
Reset
I/O Terminal Connecto
r
