112
Figure 10-8 Action Create
The following entries are displayed on this screen:
¾ Create Action
Select Policy: Select the name of the policy.
Select ACL: Select the ACL for configuration in the policy.
10.3 Policy Binding
Policy Binding function can have the policy take its effect on a specific port/VLAN. The policy will
take effect only when it is bound to a port/VLAN. In the same way, the port/VLAN will receive the
data packets and process them based on the policy only when the policy is bound to the
port/VLAN.
The Policy Binding can be implemented on Binding Table, Port Binding and VLAN Binding
pages.
10.3.1 Binding Table
On this page view the policy bound to port/VLAN.
Choose the menu ACL→Policy Binding→Binding Table to load the following page.
Figure 10-9 Binding Table
The following entries are displayed on this screen:
¾ Search Option
Show Mode: Select a show mode appropriate to your needs.
¾ Policy Bind Table
Select: Select the desired entry to delete the corresponding binding policy.
Index: Displays the index of the binding policy.
Policy Name: Displays the name of the binding policy.
