Table 10: Scope of delivery
6.5 Unpacking and inspecting the equipment
Carefully unpack the equipment. Damages due to transportation must immediately be reported to the
shipping company. Save the shipping container and all packing material to substantiate your claim.
For storage or reshipment the original packing material should be used.
6.6 Mounting
• In cooperation with the maintenance shop, mounting details are specified. The maintenance
shop can manufacture and install all cables that may be required.
• Avoid installing the unit in the vicinity of heat sources. Sufficient air circulation is required.
• There must be sufficient space for cables and connectors.
• Avoid sharp bends and wiring close to control cables.
• Cable length must be such that connectors are accessible for repair.
• The wiring to the transceiver must be installed such that water droplets formed by condensation
will not run into the connector.
• Remove the turning knob in order to install the transceiver:
o Remove the turning knob cap with an appropriate tool.
o Loosen the screw and remove the turning knob.
o Install cap correctly oriented
• Installation is from the front side of the instrument panel with four 4mm screws in a panel cut-out
as indicated in “6.8.4 Wiring Diagram”.
• For installation details and drawings refer to chapter “6.8.4 Wiring Diagram”.
6.7 Electrical connections
The 15-pin D-Sub connector contains all electrical connections except the antenna.
