TRANSMITTER
Power Output 6 W (nominal) at >13.5V
4 W (minimal)
Harmonic Distortion <10 % at 70 % modulation
Sidetone Output >0,5W an 300Ω (head set output)
Microphone Inputs 2 x standard (50mV…2V) into 100Ω or 2 x dynamic
Harmonic Content > 60dBc
Modulation Fidelity deviation <6 dB von 350…2500Hz
Carrier Noise Level >35dB at 70% Modulation index
Unwanted Frequency Modulation <1kHz at m=70% / 1kHz
Duty Cycle 2 minutes on, 4 minutes off; automatic turn-off after 2 minutes con-
tinuous transmitter operation
Table 13: Technical Data Transmitter
RECEIVER
Sensitivity -105 dBm (>6 dB S+N/N, m = 30 % / 1 kHz)
Bandwidth / 25 KHZ -6-dB-bandwidth > ±8.0 kHz
Bandwidth / 8.33 KHZ -6-dB-bandwidth > ±2.78 kHz
Selectivity (channel spacing 25
KHZ)
-40-dB-bandwidth < ±17.0 kHz
-60-dB-bandwidth < ±22.0 kHz
Selectivity (channel spacing 8.33
KHZ)
-60-dB-bandwidth < ±7.37 kHz
Speaker Output ≥10 W into 4 Ω
AGC Characteristics Deviation of NF-output < 6 dB from 10 µV to 10 mV
Squelch Automatic Squelch (adjustable)
Spurious Responses > 80 dB
Distortion (350…2500Hz) <25% at rated power (85% / -33dBm)
<10% at 10dB below rated power (70% / -33dBm)
Table 14: Technical Data Receiver
