Page 2-5 Installation Instructions TQG191-IM
Rev 0: 28 Feb 2019
2.6.2 L-Band ADS-B Antennas
The L-Band antenna used with the KTX2 must adhere to the following specifications:
Standard 50 W, vertically polarized antenna with a VSWR < 1.7:1 at 1090 MHz.
TSO-C66( ), TSO-C74( ), TSO-C112( ) , or TSO-154c antennas that also meet the VSWR
specification.
Only the L-Band antennas listed in Table 2-6 have been tested for compatibility with
KTX2 installations.
Table 2-6: L-Band Antennas
