Page 4-8 Installation Checkout TQG191-IM
Rev 0: 28 Feb 2019
4.3.5 Squawk IDENT
On request of the air traffic control, push the ID button (when not in the STBY mode).
Transmission of the ID signal will last for 18 seconds and “IDT” is displayed above the mode
and left side of the Flight ID ( ).
Figure 4-5: Squawk IDENT
4.3.6 Flight / Ground Indication
Aircraft with AIR/GROUND switches display “FLY” (Flight) or “GND” (Ground) in the lower right
corner (Figure 4-6).
Figure 4-6: FLY / GND
This function must be activated in the set-up procedure (see paragraph 4.4.2.4).
When this function is not activated, there are no indications on the display and modes must
be manually selected in accordance with Table 4-5.
4.3.7 Adjustable Parameters in Operation Mode
4.3.7.1 Flight ID
To modify the Flight ID (FID) during operation, push the ID button for at least 3 seconds.
Figure 4-7:: Modify Flight ID
