Page 4-12 Installation Checkout TQG191-IM
Rev 0: 28 Feb 2019
4.4.2 Configuration Pages
4.4.2.1 Set Flight ID (FID)
Before you can enter the 24-bit Aircraft Address (AA), the Flight ID needs to be defined.
1. Rotate the Rotary Knob to select Flight ID;
2. Push the Rotary Knob to enter the Flight ID sub-menu;
3. Select “Add” to add a Flight ID, modify to modify or delete to delete a Flight ID by
pushing the rotary knob;
4. In the “Add” sub-menu, the following screen appears:
5. Press and rotate the rotary knob to enter the Flight ID. Press to jump to the next digit,
rotate to select the desired character until the Flight ID is complete.
6. When selection is done, turn rotary knob to move cursor to “Save”, save configuration by
pushing the rotary knob.
7. Leave the menu by moving to the first line (“Edit FID Param.”) and by pushing the rotary
knob
