TQ KTX2 Installation Manual

Page iv TQG191-IM
Rev 0: 28 Feb 2019
KTX2
Installation Manual
3.3.11! KTX2 Final Installation Steps .............................................................................3-14!
3.4! REQUIRED PLACARDS AND MARKINGS .........................................................3-14!
3.5! REMOVE AND REPLACEMENT PROCEDURES ...............................................3-14!
SECTION 4! INSTALLATION CHECKOUT ........................................................................... 4-1!
4.1! INTRODUCTION ....................................................................................................4-1!
4.2! BASIC DISPLAYS AND CONTROLS ....................................................................4-1!
4.2.2! Controls ...............................................................................................................4-2!
4.2.3! Display Indications ...............................................................................................4-3!
4.2.4! Extended Squitter (ADS-B) Indications ................................................................4-4!
4.3! NORMAL OPERATION ..........................................................................................4-5!
4.3.1! ON/OFF ...............................................................................................................4-6!
4.3.2! Select Transponder Modes ..................................................................................4-7!
4.3.3! Changing the Squawk ..........................................................................................4-7!
4.3.4! VFR Squawk........................................................................................................4-7!
4.3.5! Squawk IDENT ....................................................................................................4-8!
4.3.6! Flight / Ground Indication .....................................................................................4-8!
4.3.7! Adjustable Parameters in Operation Mode ..........................................................4-8!
4.4! CONFIGURATION SET-UP ...................................................................................4-9!
4.4.1! Entering Set-Up Mode .........................................................................................4-9!
4.4.2! Configuration Pages ..........................................................................................4-12!
4.4.3! Factory Reset ....................................................................................................4-17!
4.4.4! Test Menu .........................................................................................................4-18!
4.4.5! Errors and Warnings ..........................................................................................4-19!
4.5! POST-INSTALLATION CHECKOUT ...................................................................4-20!
4.5.1! General..............................................................................................................4-20!
4.5.2! KTX2 Operational Checks .................................................................................4-20!
4.5.3! GPS Source Check............................................................................................4-20!
4.5.4! ADS-B Out Check ..............................................................................................4-21!
4.5.5! Static System Check..........................................................................................4-21!
4.5.6! Electromagnetic Interference (E.M.I.) Check......................................................4-21!
4.5.7! Flight Test ..........................................................................................................4-23!
4.5.8! Installation Checkout Complete .........................................................................4-23!
SECTION 5! MAINTENANCE ................................................................................................ 5-1!
5.1! INTRODUCTION ....................................................................................................5-1!
5.2! CONTINUED AIRWORTHINESS............................................................................5-1!
5.2.1! Periodic Maintenance KTX2 ................................................................................5-1!
5.3! FAULT ISOLATION ...............................................................................................5-1!
5.4! RETURN TO SERVICE ..........................................................................................5-3!
5.5! DISPOSITION OF FAILED ITEMS .........................................................................5-3!
APPENDIX A FCC RELATED ISSUES ..................................................................................... 1!
A.1! RADIOFREQUENCY RADIATION EXPOSURE INFORMATION ............................. 1!
A.2! COMPLIANCE .......................................................................................................... 1!
