TR-Electronic CD_-582 Series - 1 General information; 1.1 Applicability

General information
 TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 6 of 29 TR - ECE - BA - GB - 0142 - 01 06/12/2019
1 General information
This Manual addresses the following topics:
● General functional description
● Basic safety information with declaration of the intended use
● General specifications
● Assembly
Since it has a modular structure, this Manual is supplementary to other documentations, such as
product data sheets, dimensional drawings, brochures, interface-specific user manuals, etc.
1.1 Applicability
This Manual applies exclusively to measuring system series according to the following keys for article
numbers and types:
Article number
* 1 * 2 * 3 * 4 * 5 - * 6 * 6 * 6 * 6 * 6
Position Designation Description
* 1
A
Explosion protection enclosure (ATEX);
C
Absolute encoder, programmable
* 2
D
Redundant dual scanning unit
* 3
V
Solid shaft
H
Hollow shaft
S
Blind shaft
W
Rope length transmitter (wire)
* 4
582
Outer diameter
∅
58 mm, Generation 2
* 5
M
Multi-turn
S
Singleturn
* 6
-
Consecutive number
* = placeholder
Type key
See Revision Lists:
CD_582M +FS02: www.tr-electronic.de/f/TR-ECE-TI-D-0343
CD_582M +FS03: www.tr-electronic.de/f/TR-ECE-TI-D-0349
