Overcurrent protection for the battery cables must be provided as part of the system
installation. Refer to local electrical codes for requirements.
Although over current protection for the DC output wiring is provided as an integral part of
this unit, additional over current protection of the DC output wiring may be required as part
of the system installation. Refer to local electrical codes for requirements.
GROUNDING INSTRUCTIONS - This charge/load controller should be connected to a
grounded, metal, permanent wiring system. Connections to the grounding system should
comply with all local codes and ordinances.
Someone should be within range of your voice or close enough to come to your aid when
you work near batteries.
Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or
eyes.
Wear eye protection and protective clothing. Avoid touching eyes while working near
batteries.
If battery acid contacts skin or clothing, wash immediately with soap and water. If acid
enters an eye, immediately flood the eye with running cold water for at least 15 minutes and
get medical attention immediately.
Baking soda neutralizes spilled lead acid electrolyte. Vinegar neutralizes spilled NiCad
electrolyte. Keep a supply on hand.
NEVER smoke or allow a spark or flame in vicinity of a battery or generator.
Be extra cautious to reduce the possibility of dropping a metal tool onto
batteries, it might short-circuit batteries or other electrical parts that may
cause an explosion. Cover wrench handles with plastic tape or vinyl dip-
coating material.
Remove personal metal items such as rings, bracelets, necklaces, and
watches while installing the system. A single battery can produce a short-
circuit current high enough to weld a ring to a battery terminal, causing severe burns.
MicroSine miniture utility-interactive inverter fits on back of 24-volt PV solar module.
Allows you to ‘sell back’ power to the utility grid (not for charging batteries or UPS)
UX Series Inverters: affordable 600 to 1400 watts AC power from 12-volt DC source,
available with optional standby battery charger and remote control.
U2500 Series Inverters: 2200 to 2500 watts continuous AC power from 12, 24, 32, 36
or 48-volt DC source. Available with optional Standby charger for residential, RV, and
marine applications. Can be stacked. Optional remote available.
DR Series Inverter: 1500, 2400 or 3600 watt inverter features power-saving Search
Sense, quiet operation, stacking interface, and standard three-stage battery charger.
SW Series Inverter: True sine wave output to 230VAC from 12, 24, and 48-volt DC
sources. Stackable for up to 16.5 kilowatt, three-phase power with Search Sense,
Standby charger and multifunction LCD display; all standard equipment.
Power Module System: Complete power systems enclosed in corrosion-resistant,
powder-coated aluminum modules suitable for exterior installation. Modules can
include inverters, batteries, charge controllers, AC and DC breakers, and all associated
cabling and hardware. Factory or dealer pre-assembled.
Personal Precautions
Other Products from Trace Engineering:
!
!
!
!
!
!
Copyright Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 2680 Rev. C
5916 195 Street, NE Fax (360) 435-2229 November 4, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
