TracVision M3 User’s Guide
7
Chapter 1 - Introduction
The correct skew setting varies depending on your geographic
location, since the orientation of your antenna to the satellite changes
as you move. For example, as shown in the figure below, if your
antenna is tracking the PAS 9 satellite for Sky Mexico programming,
the ideal skew setting ranges from +30 to +70, depending upon where
you’re located within the satellite’s coverage area.
Figure 1-4 Approximate Skew Settings for the PAS 9 Satellite
For complete details about adjusting the LNB’s skew, see “Setting the
LNB Skew Angle” on page 31.
+70
+65
+60
+55
+50 +45 +40 +35 +30
