Chapter 4 - Setup
5. Carefully remove the radome and set it aside in a safe
place.
Figure 4-3 Removing the Radome
6. Locate the LNB on the back of the antenna reflector.
Figure 4-4 Location of LNB on Back of Antenna Reflector
LNB
Reflector
