11
SPECIFICATIONS
DIMENSIONS
Overall Length 58.5 in.(1700mm)
Overall Width 36 in.(1100mm)
Overall Height 43 in.(1300mm)
Wheelbase 41.7 in.(1230mm)
Front Track 32 in.(930mm)
Rear Track 28 in.(850mm)
Ground Clearance 3.5 in.(70mm)
ENGINE
Type Single, Forced air-cooled, 4-Stroke
Engine capacity 168cc
Bore x Stroke 2.67in x 2.1in
Displacement 196ml
Corrected compression ratio 8:1
Carburetor RX
Output Power 6.3 HP at 3600RPM
Maximum Torque 9.6 lb ft at 2500RPM
Starting Electric / Pull start backup
Ignition C.D.I
Lubrication Force & Splash
Transmission Automatic (C.V.T system)
Spark Plug F7RTC
Plug gap 0.7-0.8mm
Fuel Type Rq 90
Lubricate oil SAE 10W/30
CAPACITIES
Maximum load Double Seats / 400lbs
Fuel tank 0.95gal
Engine oil 3Oz
Starting <5s
Battery 12V 9Ah
Fuse 10A
Brake Track <7m@10miles/h
Top speed 25 mph (or limited as customers require)
