●Install the rear mirror and the
bumper① (Option) to the roof
frame by the use 4 bolts② M6 x 25.
Note: Make sure the mirror holder
should be fixed with its top end at
the level of the upper mark.
●Install the interior mirror (Option)
to the roof frame by the use of four
bolts③M6 x 12.
●Install the top cover (Option) ③
to the roof frame by the use of eight
washers④, bolts M6×16① , acorn
nuts ⑤and clamps②.
！ WARNING
Improper installation of the top
cover can cause possible serious
personal injury or death.
Note: 1N.m. = 0.74 lb ft
Features subject to change without notice.
Before driving please read the user manual of TrailMaster TAURUS 400UTV
carefully, you will be given with important safety information and advices.
Thanks a lot for choosing TrailMaster TAURUS 400UTV.
For more other products of TrailMaster, please visit www.bvpowersports.com
BV Powersports, LLC
Keep the pan head end of
the bolt inside the cab.
