5.5.1 Cables and Accessory Options
The T10 family has various cable assemblies and accessories depending on how the product is
to be Installed and used:
T10-Micro
The T10-Micro has No Accessories as this is a plug and play device connecting into the J1962
connector of the vehicle.
T10-Lite 2wire, 3wire, 5wire
The T10-Lite 2 through 5 wire has the following cable options:
1. 2 Wire Cable (Part No. CAB400). (No Ignition wire required).
2. 3 Wire Cable (Part No. CAB405). (Ignition wire option).
3. 5 Wire Cable (Part No. CAB410). (Ignition Wire and CAN option).
4. 5 wire to J1962 Ribbon Cable (Part No. CAB420).
5. 5 wire CAN T-Piece (Part No CAB425).
T10-Lite 9wire
The T10-Lite 9wire has the following cable options:
1. 9 Wire Cable (Part No. CAB415).
2. Generic CAN T-Piece (CAB782).
3. Driver Interface Button/LED (Part No CAB601).
4. Driver Interface Button ONLY (No LED) (Part No CAB602).
5. 5 metre extension for remote mounting of CAB601/2 (part No CAB606).
6. Dallas Driver Identification Interface (Part No CAB700)(works with TAG700).
7. Dallas Buzzer/LED Y adaptor (Part No CAB758).
8. Large Buzzer (Part No CAB754).
9. External LED (Part No CAB760).
For further information please contact Orders@trakm8.com
5.5.2 Power Ground and Ignition Installation
The T10-Micro and T10-Lite 2 wire hardware do not require connection to a vehicle ignition
sense. Both of these devices use the on board accelerometer device to sense movement and as
such incorporate a logical ignition/journey detection process. This methodology although reliable
can be flawed in slow moving traffic and also by the Start/Stop technology of modern day
vehicles. It is therefore advisable that where possible a wire ignition sense is implemented.
