T10 Installation Notes v1.7
Generic T10 Installation Notes v1.7.doc 12.08.2015
Page 22
T10-Lite Cable
9 way Molex Connector Pin Outs (CAB415)
Pin
No.
Function
Connector
Cable/wire
Colour
Implementation
1
Power
Red
Fused & protected power input, 12/24V
2
Ignition
Blue
Protected logic level clamped input
3
Ground (Power)
Black
Ground connection
4
Dallas 1-Wire
Black/White
IO with open collector drive with 4k7 pull-up to
4V4
5
LED (Buzzer)
White
Switched 4V4 Power feed via 100R series resistor
6
Bus/Priv Button
Yellow
Protected logic input with 3v3 pull-up 10k
resistor
7
Immobiliser
White/Green
Open collector output
8
CAN-H/K-Line
Green/White
CAN High (70-35A) / K-Line (70-30A)
9
CAN-L/ PTO input
Blue/White
CAN Lo (70-35A) / PTO input (70-30A
5.5.10 Engineering Mode
The T10-Lite has an engineering mode to assist installation and test engineers out in the field.
Engineering Mode is entered by issuing the SETENG command for the T10-Micro and T10-Lite
products. The T10-Lite product can use the driver interface button (CAB601) to enter engineering
mode. To enter engineering mode press the driver interface button >10 times. The led will come
on solid for a short period indicating that it is in engineering mode. It will then flash once
indicating that it is in screen one. While in engineering mode a single press of the driver
interface button will advance to the next screen.
To leave engineering mode repeat the pressing of the driver button > 10 times.
Engineering screen 1 (GSM/GPRS/GPSCAN connectivity indication)
0 trill = no network coverage
1 trill = GSM ok
2 trill = GSM & GPRS ok
3 trill = GSM, GPRS & Jabber connection connected ok
And
0 flash = No GPS coverage
1 flash = 1 satellite, time fix possible
2 flash = 2D GPS fix
3 flash = 3D GPS fix
And
0 Pulse = No CAN connection
1 Pulse = CAN Connection
2 Pulse = RPM Detected, Engine Running
Engineering screen 2 (Ignition detection)
Led On Ignition On
Led Off Ignition Off
Engineering screen 3 (External power detection)
You must have the internal Battery connected for this screen to operate correctly
Led On Ext Power present
Led Off Ext power absent
