5.5.9 Cable Assemblies
The following section is a quick reference guide to all of the Main Cable looms used within the
T10 Family.
T10-Micro Cables
There are no cables associated with the T10-Micro.
T10 MiniLite Cables
2 way Molex Connector Pin Outs (CAB400)
Pin
Wire Colour
Function
Description
1
Red
Power V+ (6v to 30v)
Vehicle Power - 12/24V
2
Blue
Digital Input (Voltage sensing)
Ignition input
3 way Molex Connector Pin Outs (CAB405)
Pin
Wire Colour
Function
Description
1
Red
Power V+ (6v to 30v)
Vehicle Power - 12/24V
2
Blue
Digital Input (Voltage sensing)
Ignition input
3
Black
GND
Signal Ground (1-Wire)
5 way Molex Connector Pin Outs (CAB410)
Pin
Wire Colour
Function
Description
1
Red
Power V+ (6v to 30v)
Vehicle Power - 12/24V
2
Blue
Digital Input (Voltage sensing)
Ignition input
3
Black
GND
Signal Ground (1-Wire)
4
Green / White
CAN-H
CAN High connection
5
Blue / White
CAN-L
CAN Low connection
