Optional Accessories
Accessory Number Description
Fits Cabinet Size
BAYEA(AC/13)04BK1 Electric Heater, 4kW, Breaker, 24V Control, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)04LG1 Electric Heater, 4kW, Lugs, 24VControl, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)05BK1 Electric Heater, 5kW, Breaker, 24V Control, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)05LG1 Electric Heater, 5kW, Lugs, 24VControl, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)08BK1 Electric Heater, 8kW, Breaker, 24V Control, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)08LG1 Electric Heater, 8kW, Lugs, 24VControl, 1 Ph
17.5" to 23.5"
BAYEA(AC/1310BK1 Electric Heater, 10kW, Breaker, 24V Control, 1 Ph
17.5" to 23.5"
BAYEA(AC/13)10LG1 Electric Heater, 10kW, Lugs, 24VControl, 1 Ph
17.5" to 23.5"
BAYEA(BC/23)15BK1 Electric Heater, 15kW, Breaker, 24V Control, 1 Ph
21.0" to 23.5"
BAYEA(BC/2320BK1 Electric Heater, 20kW, Breaker, 24VControl, 1 Ph
23.5"
BAYEA(CC/33)25BK1 Electric Heater, 25kW, Breaker, 24V Control, 1 Ph
23.5"
BAYEA(AC/13)10LG3 Electric Heater, 10kW, Lugs, 24VControl, 3 Ph
17.5" to 23.5"
BAYEA(BC/23)15LG3 Electric Heater, 15kW, Lugs, 24V Control, 3 Ph
21.0" to 23.5"
BAYSUPFLGAA
Supply Duct Flange 1
17.5"
BAYSUPFLGBA
Supply Duct Flange 2
21.0"
BAYSUPFLGCA
Supply Duct Flange 3
23.5"
BAYRETFLGAA
Return Duct Flange 1
17.5"
BAYRETFLGBA
Return Duct Flange 2
21.0"
BAYRETFLGCA
Return Duct Flange 3
23.5"
BAYSRKIT100A Side Return Kit 17.5" to 23.5"
BAYFLR1620A
High Velocity Filter Kit, 16” x 20” x 1” (10 filters)
17.5"
BAYFLR2020A
High Velocity Filter Kit, 20” x 20” x 1” (10 filters)
21.0"
BAYFLR2220A
High Velocity Filter Kit, 22” x 20” x 1” (10 filters)
23.5"
TASB175SB
(a) (b)
Plenum Stand with integrated sound baffle 1
17.5"
TASB215SB
Plenum Stand with integrated sound baffle 2
21.0"
TASB235SB
Plenum Stand with integrated sound baffle 3
23.5"
MITISRKIT01A Side Return Kit with 16” x 20” Filter 17.5" to 23.5"
BAYFRKIT175 Front Return Kit for 17.5” Cabinet 17.5"
BAYFRKIT210 Front Return Kit for 21.0” Cabinet 21.0"
BAYFRKIT235 Front Return Kit for 23.5” Cabinet 23.5"
TAYBASETAMA Downflow Sub-Base Kit 17.5" to 23.5"
BAYBAFKT175A
(c)
Sound Baffle Kit for 17.5” Cabinet 17.5"
BAYBAFKT215A Sound Baffle Kit for 21.0” Cabinet 21.0"
BAYBAFKT235A Sound Baffle Kit for 23.5” Cabinet 23.5"
TASSBK175
(d) (e)
Sound Baffle Kit for 17.5” Cabinet 17.5"
TASSBK210 Sound Baffle Kit for 21.0” Cabinet 21.0"
TASSBK235 Sound Baffle Kit for 23.5” Cabinet 23.5"
BAYICSKIT01A Internal Condensate Switch Kit 17.5" to 23.5"
BAYHHKIT001A
Horizontal Hanger Kit
17.5" to 23.5"
BAYUVCLK001A
UVC Lights
17.5" to 23.5"
BAYLVKIT100A
Low Voltage Conduit Entry Kit
17.5" to 23.5"
BAYSPEKT200A
Single Power Entry Kit
17.5" to 23.5"
BAYWAAA05SC1AA
Hydronic Coil — 50,000 BTUH — Slide-in
17.5" to 17.5"
BAYWABB07SC1AA
Hydronic Coil — 70,000 BTUH — Slide-in
21.0" to 21.0"
BAYWACC08SC1AA
Hydronic Coil — 80,000 BTUH — Slide-in
23.5" to 23.5"
BAYWACC11SC1AA
Hydronic Coil — 100,000 BTUH — Add on
23.5" to 23.5"
BAYWACNTKT05
Relay Kit for use with BAYWAAA05SC1A
17.5"
BAYWACNTKT07
Relay Kit for use with BAYWABB07SC1A
21.0"
BAYWACNTKT08
Relay Kit for use with BAYWACC08SC1A
23.5"
BAYWACNTKT11
Relay Kit for use with BAYWACC11SC1A
23.5"
BAYINSKT175A
Solcoustic® Liner Kit for 17.5” cabinet
17.5"
BAYINSKT215A
Solcoustic® Liner Kit for 21.5” cabinet
21.0"
BAYINSKT235A
Solcoustic® Liner Kit for 23.5” cabinet
23.5"
BAYCNDPIP01A
3/4” PVC Threaded Pipe Kit foam Seal (10 per box)
17.5" to 23.5"
BAYSENSC360
Supply Air Temperature Sensor
17.5" to 23.5"
(a)
Contact your distributor for information.
(b)
In open air applications, the plenum stand with sound baffle provides sound reduction.
(c)
Mounts inside air handler filter channel.
(d)
In return plenum applications, use TASSBK for sound reduction.
(e)
Mounts to TASB original plenum stand without integrated baffle.
