Dimensional Diagrams
Indoor Unit:
Outdoor Unit:
A
B
C
G
K
I
H
D
J
F
E
Note: The dimensions in these drawings are rounded according to standard measurement.
Model
Indoor Unit (inch/mm) Outdoor Unit (inch/mm)
ABCD E F GHI JK
9K
31.93/
811
11.50/
292
7.95/
202
28.03/
712
19.61/
498
9.21/
234
16.34/
415
11.46/
291
8.86/
225
1.91/
48.5
2.05/
52
12K
31.93/
811
11.50/
292
7.95/
202
28.03/
712
19.61/
498
9.21/
234
16.34/
415
11.46/
291
8.86/
225
1.91/
48.5
2.05/
52
18K
39.76/
1010
12.4/
315
8.66/
220
31.3/
795
21.61/
549
9.92/
252
17.09/
434
12.0/
305
10.94/
278
1.89/
48.0
2.48/
63
24K
46.69/
1186
13.39/
340
10.55/
268
33.27/
845
27.28/
693
13.23/
336
23.07/
586
14.76/
374.9
13.68/
347.5
2.31/
58.6
2.56/
65
17 Series Mini-Split
