Trane 17 Series User Manual

Space to the ceilling
At least 150mm/0.49ft
At least 1 50mm /0.49ft
At least 3000mm/9.84ft
Space to the wall
At least 1 50mm /0.49ft
Space to the wall
Space to the obstruction
At least 2500mm/8.2ft
Space to the floor
At least 500mm/1.64ft
Space to the obstruction
At least 3
00mm/0
.98ft
Space to the obstr
uction
A
t least 300
m
m/0.98ft
Space to
t
he wall
Space to the obstruction
At least
2000mm/6.56ft
A
t least 300mm/0.98ft
Space to the obstruction
Drainage pipe
Connecting wire
Note: The maximum recommended height from the fl oor to the bottom of the indoor unit is
11.5 ft. (3.5 m).
Clearance Requirements
17 Series Mini-Split
