Trane 5 Series User Manual

GAM5-SF-1P-EN 10
WIRING DATA
GAM5B0A18M11SB, GAM5B0A18M11EA
Heater
Model
No.
No.
of
Circuits
240 VOLT 208 VOLT
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater - - - 2.8* 4 15 - - 2.8* 4 15
BAYEAAC04BK1
BAYEAAC04LG1
1 3.84 13100 16.0 24 25 2.88 9800 13.8 21 25
BAYEAAC05BK1
BAYEAAC05LG1
1 4.80 16400 20.0 29 30 3.60 12300 17.3 25 25
BAYEAAC08BK1
BAYEAAC08LG1
1 7.68 26200 32.0 44 45 5.76 19700 27.7 38 40
BAYEAAC10BK1①
BAYEAAC10LG1①
1 9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
BAYEAAC10LG3② 1-3 PH 9.60 32800 23.1 32 35 7.20 24600 20.0 28 30
Note: * Motor Amps
① Heater not qualified for downflow installations
② Approved for 240 V only with Heat Pump
WIRING DATA
GAM5B0A24M21SB, GAM5B0A24M21EA
Heater
Model
No.
No.
of
Circuits
240 VOLT 208 VOLT
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater - - - 2.8* 4 15 - - 2.8* 4 15
BAYEAAC04BK1
BAYEAAC04LG1
1 3.84 13100 16.0 24 25 2.88 9800 13.8 21 25
BAYEAAC05BK1
BAYEAAC05LG1
1 4.80 16400 20.0 29 30 3.60 12300 17.3 25 25
BAYEAAC08BK1
BAYEAAC08LG1
1 7.68 26200 32.0 44 45 5.76 19700 27.7 38 40
BAYEAAC10BK1①
BAYEAAC10LG1①
1 9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
BAYEAAC10LG3② 1-3 PH 9.60 32800 23.1 32 35 7.20 24600 20.0 28 30
Note: * Motor Amps
① Heater not qualified for downflow installations
② Approved for 240 V only with Heat Pump

Trane 5 Series Specifications

General

Refrigerant	R-410A
Stages	Variable Speed
Configuration	Horizontal or Vertical
Cooling Capacity	1.5 to 5 Tons
Airflow	Up to 2000 CFM
Voltage	208/230V
