Trane 5 Series User Manual

17 GAM5-SF-1P-EN
16 SEER Cooling Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TTR6024A*
4TTX6024G*
4A7A6024G*
GAM5B0A24M21SB
GAM5B0A24M21EA
4 H 800 0.333
2 L 725 0.273
4TTR6036A*
4TTX6036G*
4A7A6036G*
GAM5B0B36M31SB
GAM5B0B36M31EA
4 H 1225 0.357
3 L 1070 0.272
4TTR6036A*
4TTX6036G*
4A7A6036G*
GAM5B0C42M31SB
GAM5B0C42M31EA
3 H 1225 0.400
2 L 1115 0.331
4TTR6048A*
4TTX6048G*
4A7A6048G*
GAM5B0C48M41SB
GAM5B0C48M41EA
3 H 1500 0.381
2 L 1415 0.339
4TTR6060A*
4TTX6060E*
4A7A6060E*
GAM5B0C60M51SB
GAM5B0C60M51EA
3 H 1700 0.390
2 L 1645 0.365
17/18 SEER Cooling Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TTR7024A*
4TTX8024A*
4A7A7024A*
GAM5B0A24M21SB
GAM5B0A24M21EA
4 H 800 0.333
2 L 725 0.273
4TTR7036A*
4TTX8036A*
4A7A7036A*
GAM5B0B36M31SB
GAM5B0B36M31EA
4 H 1225 0.357
3 L 1070 0.272
4TTR7036A*
4TTX8036A*
4A7A7036A*
GAM5B0C42M31SB
GAM5B0C42M31EA
3 H 1225 0.400
2 L 1115 0.331
4TTR7048A*
4TTX8048A*
4A7A7048A*
GAM5B0C48M41SB
GAM5B0C48M41EA
3 H 1475 0.449
2 L 1390 0.399
4TTR7060A*
4TTX8060A*
4A7A7060A*
GAM5B0C60M51SB
GAM5B0C60M51EA
3 H 1700 0.390
2 L 1645 0.365
NOTES
1) Speed Tap settings must be changed for two stage operation
2) Speed Tap settings listed are for the rated ESP, settings may be different depending on your ESP
3) Minimum airflow for electric heat must be maintained. (High Stage)
Adjustments for 2-Stage outdoor AC models

Trane 5 Series Specifications

General

Refrigerant	R-410A
Stages	Variable Speed
Configuration	Horizontal or Vertical
Cooling Capacity	1.5 to 5 Tons
Airflow	Up to 2000 CFM
Voltage	208/230V
