Trane 5 Series User Manual

GAM5-SF-1P-EN 18
16 SEER Heat Pump Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TWR6024A*④
4TWX6024G*④
4A6H6024G*④
GAM5B0A24M21SB
GAM5B0A24M21EA
4 H 800 0.333
3 L 750 0.293
4TWR6024A*
4TWX6024G*
4A6H6024G*
GAM5B0B30M21SB
GAM5B0B30M21EA
3 H 750 0.383
2 L 665 0.301
4TWR6036A*
4TWX6036E*
4A6H6036E*
GAM5B0B36M31SB
GAM5B0B36M31EA
4 H 1150 0.500
3 L 1005 0.382
4TWR6048A*
4TWX6048G*
4A6H6048G*
GAM5B0C42M31SB
GAM5B0C42M31EA
4 H 1375 0.468
3 L 1235 0.378
4TWR6048A*
4TWX6048G*
4A6H6048G*
GAM5B0C48M41SB
GAM5B0C48M41EA
4 H 1575 0.400
2 L 1420 0.325
4TWR6060A*
4TWX6060E*
4A6H6060E*
GAM5B0C60M51SB
GAM5B0C60M51EA
3 H 1700 0.390
2 L 1645 0.365
17/18 SEER Heat Pump Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TWR7024A*④
4TWX8024A*④
4A6H7024A*④
GAM5B0A24M21SB
GAM5B0A24M21EA
4 H 800 0.333
3 L 750 0.293
4TWR7024A*
4TWX8024A*
4A6H7024A*
GAM5B0B30M21SB
GAM5B0B30M21EA
3 H 750 0.383
2 L 665 .0301
4TWR7036A*
4TWX8036A*
4A6H7036A*
GAM5B0B36M31SB
GAM5B0B36M31EA
4 H 1150 0.500
3 L 1005 0.382
4TWR7048A*
4TWX8048A*
4A6H7048A*
GAM5B0C48M41SB
GAM5B0C48M41EA
4 H 1575 0.400
2 L 1420 0.325
4TWR7060A*
4TWX8060A*
4A6H7060A*
GAM5B0C60M51SB
GAM5B0C60M51EA
3 H 1700 0.390
2 L 1645 0.365
NOTES
1) Speed Tap settings must be changed for two stage operation
2) Speed Tap settings listed are for the rated ESP, settings may be different depending on your ESP
3) Minimum airflow for electric heat must be maintained. (High Stage)
4) Subcooling must be adjusted to 9°F for this match
System Matched with: Indoor Unit Model No. Outdoor Unit Model No. Subcooling
16-18 SEER HP
GAM5B0A24M21SB
GAM5B0A24M21EA
4TWR6024A*, 4TWX6024G*
4A6H6024G*, 4TWR7024A*
4TWX8024A*, 4A6H7024A*
9°
All other matches must be charged per the nameplate charging instructions.
Adjustments for 2-Stage outdoor HP models

Trane 5 Series Specifications

General

Refrigerant	R-410A
Stages	Variable Speed
Configuration	Horizontal or Vertical
Cooling Capacity	1.5 to 5 Tons
Airflow	Up to 2000 CFM
Voltage	208/230V
