Chiller report: status, water temperatures and setpoints
“Press (Next) (Previous) to continue”
Next
Unit model
(service setting menu)
all others RTXA
Mode: [OPERATING MODE]
Request setpoint source: [SETPOINT SOURCE]
Chiller Mode: [OPERATING MODE]
Request setpoint source: [SETPOINT SOURCE]
Heat Mode: [OPERATING MODE]
Request setpoint source: [SETPOINT SOURCE]
Next
Compressors on A, B, C, D, NONE
Circuits locked out CIRCUIT 1, CIRCUIT 2, NONE
Next
[Operating mode]
Making ice,
ice-making complete All others
Active ice termination setpoint XXX C
Evaporator entering water temperature XXX.X C
Active chilled water setpoint XXX C
Evaporator leaving water temperature XXX.X C
Active hot water setpoint XXX C
Leaving water temperature XXX.X C
Next
Evaporator entering water temperature XXX.X C
Evaporator leaving water temperature XXX.X C
Next
Fan control
(Service Setting Menu)
Disable Enable
Condenser entering water temperature XXX.X C
Condenser leaving water temperature XXX.X C
Water heat recovery entering water temperature XXX.X C
Water heat recovery leaving water temperature XXX.X C
Next
Active current limit setpoint XXX %
Chiller % Rated load amps XXX %
Next
* Outdoor air temperature XXX.X C
** Zone temperature XXX.X C
7
[operating mode] will be one of
Reset
Stopped by Local Display
Stopped by Remote Display
Stopped by Tracer
Stopped by External Source
Auto
Waiting, Restart Inhibit
Starting
Running
Running, Current Limit
Running, Condenser Limit
Running, Evaporator Limit
Stopping
Making ice
ice-making complete
Low ambient temperature lockout
Electronic expansion valve test
Manufacturing test
Service pumpdown
* Dashes will be displayed if the sensor is open
or shorted and neither outdoor air reset or
low ambient lockout is enabled.
** Dashes will be displayed if the zone
temperature sensor is open or shorted or
zone reset is disabled.
Next
Next
Next
