Trane ADAPTIVE CONTROL UCM-CLD - Refrigerant Report Flowchart

Refrigerant temperature and pressure report
“Press (Next) (Previous) to continue”
Next
All others RTXA
Circuit 1 Circuit Mode: [Circuit mode]
Next
Circuit 1 evaporator refrigerant pressure XXX bar
Circuit 1 condenser refrigerant pressure XXX bar
Next
Circuit 1 compressor suction refrigerant temperature XXX.X C
Circuit 1 saturated evaporator refrigerant temperature XXX.X C
Next
Circuit 1 saturated condenser refrigerant temperature XXX.X C
Next
All others RTXA
Circuit 2 Circuit Mode: [Circuit mode]
Next
Circuit 2 evaporator refrigerant pressure XXX bar
Circuit 2 condenser refrigerant pressure XXX bar
Next
Circuit 2 compressor suction refrigerant temperature XXX.X C
Circuit 2 saturated evaporator refrigerant temperature XXX.X C
Next
Circuit 2 saturated condenser refrigerant temperature XXX.X C
Next
8
Refrigerant report
Refrigerant
report
The possible replacement to
Cooling
Heating
Defrosting
Heat to Defrost
Defrost to Heat
Cool to Heat
Heat to Cool
