Trane BACnet BCI-R User Manual

30 BAS-SVP09B-EN
Object Data Points and Diagnostic Data Points
Binary Input, 22 Economizer Airside Enable Status
Indicates the status of the airside economizer
system.
Inactive = Disabled
Active = Enabled
Binary Input, 165 Alarm Relay Output Status
Indicates the state of the alarm relay on the
unit.
Inactive = De-energized
Active = Energized
Binary Input, 292 Supply Air Tempering Status
Indicates the status of the supply air
tempering function.
Inactive = Inactive
Active = Active
Table 10. Diagnostics, Binary Input
Object Identifier Object Name Description Notification Class
Binary Input, 29 Diagnostic: Zone Temperature Sensor Failure Diagnostic: Zone Temp Sensor Failure 002 – Service Required
Binary Input, 30 Diagnostic: Supply Air Temp Sensor Fail Diagnostic: Supply Air Temp Sensor Fail 002 – Service Required
Binary Input, 32 Diagnostic: Outdoor Air Temperature Sensor Fail Diagnostic: OA Temperature Sensor Fail 002 – Service Required
Binary Input, 34 Diagnostic: Local Cool Setpoint Fail Diagnostic: Local Cool Setpoint Fail 002 – Service Required
Binary Input, 35 Diagnostic: Local Zone Heat Setpoint Fail Diagnostic: Local Zone Heat Setpoint Fail 002 – Service Required
Binary Input, 36 Diagnostic: SA Pressure Sensor Fail Diagnostic: Supply Air Press Sensor Fail 002 – Service Required
Binary Input, 37 Diagnostic: Outdoor Humidity Sensor Failure Diagnostic: OA Humidity Sensor Failure 002 – Service Required
Binary Input, 38 Diagnostic: Local Emergency Stop Initiated Diagnostic: Local Emergency Stop Initiated 001 – Critical
Binary Input, 39 Diagnostic: Fan Failure Diagnostic: Fan Failure 001 – Critical
Binary Input, 40 Diagnostic: Exhaust Fan Proving Failure Diagnostic: Exhaust Fan Proving Failure 001 – Critical
Binary Input, 43 Diagnostic: Compressor 1 LPC Lockout Diagnostic: Compressor 1 LPC Lockout 001 – Critical
Binary Input, 44 Diagnostic: Compressor 2 LPC Lockout Diagnostic: Compressor 2 LPC Lockout 001 – Critical
Binary Input, 45 Diagnostic: Coil Temp Sensor #1 Fail Diagnostic: Coil Temp Sensor 1 Fail 1 002 – Service Required
Binary Input, 46 Diagnostic: Coil Temp Sensor #2 Fail Diagnostic: Coil Temp Sensor 2 Fail 002 – Service Required
Binary Input, 47 Diagnostic: Compressor 1 HPC Lockout Diagnostic: Compressor 1 HPC Lockout 001 – Critical
Binary Input, 48 Diagnostic: Compressor 2 HPC Lockout Diagnostic: Compressor 2 HPC Lockout 001 – Critical
Binary Input, 51 Diagnostic: Heat Failure Diagnostic: Heat Failure 003 – Advisory
Binary Input, 54 Diagnostic: SA Pressure Setpoint Failure Diagnostic: SA Pressure Setpoint Failure 002 – Service Required
Binary Input, 55 Diagnostic: Space Pressure Setpoint Fail Diagnostic: Space Pressure Setpoint Fail 002 – Service Required
Binary Input, 56 Diagnostic: Space Pressure Sensor Fail Diagnostic: Space Pressure Sensor Fail 002 – Service Required
Binary Input, 57 Diagnostic: Return Air Temp Sensor Fail Diagnostic: Return Air Temp Sensor Fail 002 – Service Required
Binary Input, 58 Diagnostic: Return Air Humidity Sensor Fail Diagnostic: Return Air Humidity Sensor Fail 002 – Service Required
Binary Input, 59 Diagnostic: Auto - SA High Press Limit Diagnostic: Auto - SA High Press Limit 002 – Service Required
Binary Input, 74 Diagnostic: SA Temp Cool Setpoint Fail Diagnostic: SA Temp Cool Setpoint Fail 002 – Service Required
Binary Input, 75 Diagnostic: SA Temp Heat Setpoint Fail Diagnostic: SA Temp Heat Setpoint Fail 002 – Service Required
Binary Input, 76 Diagnostic: Dirty Filter Diagnostic: Dirty Filter 003 – Advisory
Binary Input, 83 Diagnostic: CO2 Sensor Failure Diagnostic: CO2 Sensor Failure 002 – Service Required
Binary Input, 86 Diagnostic: Velocity Press Sensor Fail Diagnostic: Velocity Press Sensor Fail 002 – Service Required
Binary Input, 95 Diagnostic: Mixed Air Temp Sensor Failure Diagnostic: Mixed Air Temp Sensor Failure 002 – Service Required
Binary Input, 106 Diagnostic: Space Humidity Sensor Fail Diagnostic: Space Humidity Sensor Fail 002 – Service Required
Binary Input, 107 Diagnostic: Entering Evap Temp Sensor Fail Diagnostic: Entering Evap Temp Sensor Fail 002 – Service Required
Binary Input, 123 Diagnostic: SA Reheat Setpoint Failure Diagnostic: SA Reheat Setpoint Failure 002 – Service Required
Binary Input, 125 Diagnostic: Dehumid Setpoint Failure Diagnostic: Dehumid Setpoint Failure 002 – Service Required
Binary Input, 147 Diagnostic: Maintenance Required Diagnostic: Maintenance Required 002 – Service Required
Binary Input, 148 Diagnostic: Unit Communications Failure Diagnostic: Unit Communications Failure 002 – Service Required
Binary Input, 151 Diagnostic: External Auto-Stop Diagnostic: External Auto-Stop 004 – Information
Binary Input, 239 Diagnostic: Morning Warmup Setpoint Fail Diagnostic: Morning Warmup Setpoint Fail 002 – Service Required
Binary Input, 242 Diagnostic: Min OA Flow Setpoint Fail Diagnostic: Min OA Flow Setpoint Fail 002 – Service Required
Binary Input, 244 Diagnostic: Comp 1 Disable Input LPC Diagnostic: Comp 1 Disable Input LPC 004 – Information
Binary Input, 245 Diagnostic: Comp 2 Disable Input LPC Diagnostic: Comp 2 Disable Input LPC 004 – Information
Table 9. Binary Input (continued)
Object Identifier Object Name Description Object States
