BAS-SVP09B-EN 31
Object Data Points and Diagnostic Data Points
Binary Input, 246 Diagnostic: Smoke Detector Diagnostic: Smoke Detector 004 – Information
Binary Input, 247 Diagnostic: FroStat Trip Diagnostic: FroStat Trip 004 – Information
Binary Input, 248 Diagnostic: Demand Defrost Fault A Diagnostic: Demand Defrost Fault A 004 – Information
Binary Input, 249 Diagnostic: Demand Defrost Fault B Diagnostic: Demand Defrost Fault B 004 – Information
Binary Input, 250 Diagnostic: Demand Defrost Fault C Diagnostic: Demand Defrost Fault C 004 – Information
Binary Input, 251 Diagnostic: Demand Defrost Fault D Diagnostic: Demand Defrost Fault D 004 – Information
Binary Input, 252 Diagnostic: Default Defrost Flag Diagnostic: Default Defrost Flag 004 – Information
Binary Input, 253 Diagnostic: Vent Override - Exhaust Diagnostic: Vent Override - Exhaust 004 – Information
Binary Input, 254 Diagnostic: Vent Override - Purge Diagnostic: Vent Override - Purge 004 – Information
Binary Input, 255 Diagnostic: Vent Override - Pressurize Diagnostic: Vent Override - Pressurize 004 – Information
Binary Input, 256 Diagnostic: Freezestat Tripped Diagnostic: Freezestat Tripped 004 – Information
Binary Input, 257 Diagnostic: CO2 Setpoint Failure Diagnostic: CO2 Setpoint Failure 004 – Information
Binary Input, 258 Diagnostic: Heating High Temp Limit Open Diagnostic: Heating High Temp Limit Open 004 – Information
Binary Input, 259 Diagnostic: Flame Rollout Switch Open Diagnostic: Flame Rollout Switch Open 004 – Information
Binary Input, 260 Diagnostic: Inducer Proving Switch Fail Diagnostic: Inducer Proving Switch Fail 004 – Information
Binary Input, 261 Diagnostic: No Flame Sensed on heat call Diagnostic: No Flame Sensed on heat call 004 – Information
Binary Input, 262 Diagnostic: Flame Sensed with Gas Valve Off Diagnostic: Flame Sensed with Gas Valve Off 004 – Information
Binary Input, 263 Diagnostic: Gas Heat Module Failure Diagnostic: Gas Heat Module Failure 004 – Information
Binary Input, 264 Diagnostic: Economizer Actuator Fault Diagnostic: Economizer Actuator Fault 004 – Information
Binary Input, 265 Diagnostic: SA Reset Amount Failure Diagnostic: SA Reset Amount Failure 004 – Information
Binary Input, 266 Diagnostic: SA Reset Setpoint Failure Diagnostic: SA Reset Setpoint Failure 004 – Information
Binary Input, 267 Diagnostic: SA Pressure Dead Band Failure Diagnostic: SA Pressure Dead Band Failure 004 – Information
Binary Input, 268 Diagnostic: SA Pressure PWM Fault Diagnostic: SA Pressure PWM Fault 004 – Information
Binary Input, 269 Diagnostic: Comp 1 Disable Input HPC Diagnostic: Comp 1 Disable Input HPC 004 – Information
Binary Input, 270 Diagnostic: Comp 2 Disable Input HPC Diagnostic: Comp 2 Disable Input HPC 004 – Information
Binary Input, 271 Diagnostic: CO2 Low Limit Setpoint Fault Diagnostic: CO2 Low Limit Setpoint Fault 004 – Information
Binary Input, 272 Diagnostic: RTOM Comm Fail Diagnostic: RTOM Comm Fail 004 – Information
Binary Input, 273 Diagnostic: RTEM Comm Fail Diagnostic: RTEM Comm Fail 004 – Information
Binary Input, 274 Diagnostic: RTAM Comm Fail Diagnostic: RTAM Comm Fail 004 – Information
Binary Input, 275 Diagnostic: RTVM Comm Fail Diagnostic: RTVM Comm Fail 004 – Information
Binary Input, 276 Diagnostic: RTCM Comm Fail Diagnostic: RTCM Comm Fail 004 – Information
Binary Input, 277 Diagnostic: RTDM Comm Fail Diagnostic: RTDM Comm Fail 004 – Information
Binary Input, 278 Diagnostic: Space Press Deadband Fail Diagnostic: Space Press Deadband Fail 004 – Information
Binary Input, 279 Diagnostic: Mod Dehumid Config Error Diagnostic: Mod Dehumid Config Error 004 – Information
Binary Input, 280 Diagnostic: Demand Defrost Fault A Ckt 2 Diagnostic: Demand Defrost Fault A Ckt 2 004 – Information
Binary Input, 281 Diagnostic: Demand Defrost Fault B Ckt 2 Diagnostic: Demand Defrost Fault B Ckt 2 004 – Information
Binary Input, 282 Diagnostic: Demand Defrost Fault C Ckt 2 Diagnostic: Demand Defrost Fault C Ckt 2 004 – Information
Binary Input, 283 Diagnostic: Defrost Default Mode Ckt 2 Diagnostic: Defrost Default Mode Ckt 2 004 – Information
Binary Input, 284 Diagnostic: Demand Defrost Fault A Ckt 1 Diagnostic: Demand Defrost Fault A Ckt 1 004 – Information
Binary Input, 285 Diagnostic: Demand Defrost Fault B Ckt 1 Diagnostic: Demand Defrost Fault B Ckt 1 004 – Information
Binary Input, 286 Diagnostic: Demand Defrost Fault C Ckt 1 Diagnostic: Demand Defrost Fault C Ckt 1 004 – Information
Binary Input, 287 Diagnostic: Defrost Default Mode Ckt 1 Diagnostic: Defrost Default Mode Ckt 1 004 – Information
Binary Input, 288 Diagnostic: Exhaust Fan Setpoint Failure Diagnostic: Exhaust Fan Setpoint Failure 004 – Information
Binary Input, 289 Diagnostic: Discharge Air Heat Setpoint Failure Diagnostic: Discharge Air Heat Setpoint Failure 004 – Information
Binary Input, 290 Diagnostic: IGN1 Communications Timed out Diagnostic: IGN1 Communications Timed out 004 – Information
Binary Input, 291 Diagnostic: IGN2 Communications Timed out Diagnostic: IGN2 Communications Timed out 004 – Information
Binary Input, 293 Diagnostic: DCV Min Position Setpoint Fail Diagnostic: DCV Min Position Setpoint Fail 004 – Information
Binary Input, 294 Diagnostic: Design Min Position Setpoint Fail Diagnostic: Design Min Position Setpoint Fail 004 – Information
Table 10. Diagnostics, Binary Input (continued)
Object Identifier Object Name Description Notification Class
