Trane BACnet BCI-R User Manual

32 BAS-SVP09B-EN
Object Data Points and Diagnostic Data Points
Binary Input, 295 Diagnostic: Enthalpy Setpoint Fail Diagnostic: Enthalpy Setpoint Fail 004 – Information
Binary Input, 296
Diagnostic: Design Min Position at Minimum Fan
Speed Fail
Diagnostic: Design Min Position at Minimum
Fan Speed Fail
004 – Information
Binary Input, 297
Diagnostic: DCV Min Position at Minimum Fan
Speed
Diagnostic: DCV Min Position at Minimum Fan
Speed
004 – Information
Binary Input, 298
Diagnostic: Design Min Position at Midpoint Fan
Speed Fail
Diagnostic: Design Min Position at Midpoint
Fan Speed Fail
004 – Information
Table 11. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects)
Object Identifier Object Name Description
Binary Input, 165 Alarm Relay Output Status Indicates the state of the alarm relay on the unit.
Analog Input, 95 BCI-R Major Version Major software version number of the BCI-R module
Analog Input, 96 BCI-R Minor Version Minor software version number of the BCI-R module
Analog Input, 80 Cabinet Style Describes the cabinet style of the unit.
Binary Input, 2 Compressor Lockout Status One or more compressors are locked out with no diagnostic.
Analog Output, 19 Cool Capacity Enable Setpoint BAS BAS supplied cooling demand limit capacity setpoint value.
Binary Output, 6 Cool Lockout Command Command the unit to prevent cooling operation.
Multi-State Input, 25 Cool Output 1 Indicates the commanded state of cooling output 1.
Multi-State Input, 26 Cool Output 2 Indicates the commanded state of cooling output 2.
Analog Input, 81 Cool Type Describes the cooling type installed in the unit.
Analog Input, 1 Cooling Capacity Status Indicates the unit cooling capacity being utilized.
Multi-State Input, 22 Cooling Setpoint Source Indicates the source of the space cooling setpoint.
Binary Output, 21 Daytime Warmup Enable Command Command the unit daytime warmup operation
Analog Output, 5 Daytime Warmup Terminate Temperature Setpoint BAS BAS supplied daytime warmup terminate temperature setpoint.
Analog Input, 79 Dehumidification Capacity Status Indicates the unit dehumidification capacity being utilized.
Binary Output, 15 Dehumidification Enable Command Command the operating state of the dehumidification system.
Analog Input, 58 Dehumidification High Limit Setpoint Humidity setpoint value that starts dehumidification control.
Analog Output, 6 Discharge Air Cooling Setpoint BAS BAS supplied discharge air temperature cooling setpoint value.
Analog Output, 7 Discharge Air Heating Setpoint BAS BAS supplied discharge air temperature heating setpoint value.
Analog Input, 61 Discharge Air Reheat Setpoint Active Indicates the active supply air reheat temperature setpoint.
Analog Output, 23 Discharge Air Reheat Setpoint BAS BAS supplied discharge air reheat setpoint value.
Analog Input, 24 Discharge Air Temperature Active The discharge air temperature currently used for unit control.
Analog Input, 52 Discharge Air Temperature Setpoint Active Discharge air temperature setpoint value being used for unit control.
Analog Input, 28 Duct Static Pressure Active Duct static air pressure value currently being used for unit control.
Analog Input, 48 Duct Static Pressure Setpoint Active Duct static pressure setpoint value being used for unit control.
Analog Output, 8 Duct Static Pressure Setpoint BAS BAS supplied duct static air pressure setpoint value.
Multi-State Output, 1 Economizer Airside Enable BAS Command the state of the airside economizer system.
Binary Input, 22 Economizer Airside Enable Status Indicates the status of the airside economizer system.
Binary Output, 7 Economizer Minimum Position Enable Command Command the unit to the minimum position operation.
Analog Output, 1 Economizer Minimum Position Setpoint BAS BAS supplied economizer position minimum setpoint value
Analog Input, 86 Economizer Minimum Position Setpoint Local Indicates the local economizer minimum position setpoint.
Multi-State Input, 44 Economizer System Status Indicates the operating state of the waterside economizer system.
Multi-State Output, 2 Emergency Override Command Command the unit into an emergency mode of operation.
Analog Input, 9 Exhaust Damper Position Status Indicates the unit exhaust damper position.
Analog Input, 71 Exhaust Enable Damper Position Setpoint Status Exhaust air damper minimum position to enable exhaust sequence.
Multi-State Input, 39 Exhaust Fan Proving Status Indicates if the unit exhaust fan is off or on.
Table 10. Diagnostics, Binary Input (continued)
Object Identifier Object Name Description Notification Class
