BAS-SVP09B-EN 33
Object Data Points and Diagnostic Data Points
Analog Input, 8 Exhaust Fan Speed Command Indicates the unit commanded exhaust fan speed.
Multi-State Input, 38 Exhaust Fan Status Indicates the commanded state of the exhaust fan.
Analog Output, 33 Exhaust or Return Fan Configuration Sets the equipment exhaust or return fan type.
Analog Input, 90 Exhaust or Return Fan Type Describes the exhaust or return fan type installed in the unit.
Analog Input, 6 Filter Runtime Hours Indicates the number of hours air has flowed through the filter.
Analog Value, 1 Filter Runtime Hours Setpoint The setpoint value used by the filter run hours calculation.
Binary Output, 13 Filter Timer Reset Command the unit to reset the accumulated filter run hours.
Analog Output, 20 Heat Capacity Enable Setpoint BAS BAS supplied heating demand limit capacity setpoint value.
Multi-State Output, 8 Heat Cool Mode Request BAS Command the unit to a specific application mode.
Binary Output, 5 Heat Lockout Command Command the unit to prevent heating operation.
Multi-State Input, 29 Heat Output 1 Indicates the commanded state of heating output 1.
Multi-State Input, 30 Heat Output 2 Indicates the commanded state of heating output 2.
Multi-State Input, 31 Heat Output 3 Indicates the commanded state of heating output 3.
Multi-State Input, 32 Heat Output 4 Indicates the commanded state of heating output 4.
Analog Input, 2 Heat Primary Capacity Status Indicates the unit primary heating capacity being utilized.
Analog Input, 3 Heat Secondary Capacity Status Indicates the unit secondary heating capacity being utilized.
Multi-State Input, 23 Heating Setpoint Source Indicates the source of the space heating setpoint.
Binary Output, 19 Lead-Lag Enable Command Command the unit compressor startup order
Analog Input, 25 Mixed Air Temperature The mixed air temperature value from a unit-mounted sensor.
Binary Output, 20 Morning Warmup Enable Command Command the unit morning warmup operation
Analog Output, 4 Morning Warmup Setpoint BAS BAS supplied temperature setpoint used in morning warmup mode.
Analog Input, 54 Morning Warmup Temperature Setpoint Active The air temperature setpoint used during morning warmup mode.
Multi-State Output, 7 Occupancy Request Command the unit into an occupancy mode.
Multi-State Input, 20 Occupancy Status Indicates the current occupancy mode of the unit.
Analog Output, 29 Occupied Offset Offset used to calculate setpoints in occupied mode.
Analog Input, 11 Outdoor Air Damper Position Status Indicates the unit outdoor air damper position.
Analog Input, 34 Outdoor Air Flow Active Outdoor airflow utilitzed by the unit.
Analog Input, 20 Outdoor Air Humidity Active The outdoor air humidity value used for unit control.
Analog Output, 15 Outdoor Air Humidity BAS BAS supplied outdoor air humidity sensor value.
Analog Input, 57 Outdoor Air Minimum Flow Setpoint Active The minimum outdoor airflow setpoint being utilized by the unit.
Analog Output, 16 Outdoor Air Minimum Flow Setpoint BAS BAS supplied minimum outdoor airflow setpoint.
Analog Input, 18 Outdoor Air Temperature Active The outdoor air temperature currently used for unit control.
Analog Output, 14 Outdoor Air Temperature BAS BAS supplied outdoor air temperature sensor value.
Multi-State Input, 43 Outdoor Damper Status Indicates the operating state of the outdoor damper.
Analog Output, 34 Power Exhaust Enable Setpoint BAS BAS supplied power exhaust enabled setpoint value.
Analog Input, 82 Preheat Type Describes the heating type installed in the unit.
Multi-State Input, 35 Primary Filter Status Indicates the primary filter media state.
Analog Input, 5 Reheat Capacity Status Indicates the unit reheat heating capacity being utilized.
Analog Input, 83 Reheat Type Describes the reheat type installed in the unit.
Binary Output, 14 Reset Diagnostic Command the unit to reset and clear diagnostics.
Analog Input, 26 Return Air Temperature The return air temperature value from a unit-mounted sensor.
Analog Input, 97 RTAM Major Version Major software version number of the RTAM module
Analog Input, 98 RTAM Minor Version Minor software version number of the RTAM module
Analog Input, 105 RTCM Major Version Major software version number of the RTCM module
Analog Input, 106 RTCM Minor Version Minor software version number of the RTCM module
Analog Input, 101 RTDM Major Version Major software version number of the RTDM module
Table 11. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) (continued)
Object Identifier Object Name Description
