Object Data Points and Diagnostic Data Points
Analog Input, 102 RTDM Minor Version Minor software version number of the RTDM module
Analog Input, 99 RTEM Major Version Major software version number of the RTEM module
Analog Input, 100 RTEM Minor Version Minor software version number of the RTEM module
Analog Input, 93 RTOM Major Version Major software version number of the RTOM module
Analog Input, 94 RTOM Minor Version Minor software version number of the RTOM module
Analog Input, 91 RTRM Major Version Major software version number of the RTRM module
Analog Input, 92 RTRM Minor Version Minor software version number of the RTRM module
Analog Input, 103 RTVM Major Version Major software version number of the RTVM module
Analog Input, 104 RTVM Minor Version Minor software version number of the RTVM module
Binary Output, 17 Service Test Command Command the unit to step through service test
Binary Input, 11 Service Test Mode Status Indicates if the unit is in service test mode.
Multi-State Input, 45 Service Test Status Indicates the current Service Test state
Analog Input, 32 Space CO
2
Concentration Active Space CO
2
concentration being used for unit control.
Analog Output, 18 Space CO
2
Concentration BAS BAS supplied space CO
2
sensor value.
Analog Output, 21 Space Dehumidification Setpoint BAS BAS supplied space dehumidification setpoint value.
Analog Input, 16 Space Humidity Active The space humidity value from a unit-mounted control.
Analog Output, 25 Space Humidity BAS BAS supplied space humidity sensor value.
Analog Input, 31 Space Static Air Pressure Active Space static air pressure value being used for unit control.
Analog Output, 10 Space Static Pressure BAS BAS supplied space static air pressure sensor value.
Analog Input, 107 Space Static Pressure Setpoint Active Space pressure setpoint currently used for unit control
Analog Output, 9 Space Static Pressure Setpoint BAS BAS supplied space static air pressure setpoint value.
Analog Input, 15 Space Temperature Active The space temperature currently used for unit control.
Analog Output, 11 Space Temperature BAS BAS supplied space air temperature sensor value.
Analog Input, 74 Space Temperature Cooling Setpoint Input Cooling temperature setpoint from space sensor module.
Analog Input, 75 Space Temperature Heating Setpoint Input Heating temperature setpoint from space sensor module.
Analog Input, 87 Space Temperature Local The space air temperature measured by a unit-mounted sensor.
Analog Input, 50 Space Temperature Setpoint Active Space temperature setpoint value being used for unit control.
Analog Output, 2 Space Temperature Setpoint BAS Base value to calculate setpoints in occupied and standby modes.
Analog Input, 78 Space Temperature Setpoint Local The local space temperature setpoint.
Analog Output, 30 Standby Offset Offset value used to calculate setpoints in standby mode.
Binary Output, 18 Supply Air Tempering Enable Command Command the unit supply air tempering operation.
Binary Input, 292 Supply Air Tempering Status Indicates the status of the supply air tempering function.
Binary Output, 8 Supply Fan Configuration Command Command the unit supply fan to cycling or continuous operation.
Binary Input, 15 Supply Fan Configuration Status Indicates the supply fan configuration.
Multi-State Input, 37 Supply Fan Proving Status Indicates the current state of the supply fan.
Analog Input, 7 Supply Fan Speed Command Indicates the unit commanded supply fan speed.
Multi-State Input, 41 Supply Fan Status Indicates the state of the supply fan.
Analog Input, 89 Supply Fan Type Describes the supply fan type installed in the unit.
Binary Output, 1 System Control Command Command the unit to standalone- or BAS-controlled operation.
Binary Input, 1 System Control Status Indicates the control system currently in command of the unit.
Multi-State Input, 24 Timed Override Status Timed override request or cancel from zone sensor.
Analog Input, 88 Unit Energy Demand Indicates the current heat/cool energy demand of the unit.
Multi-State Input, 21 Unit Stop Source Source of the stop command that turned off the equipment.
Analog Output, 31 Unoccupied Cooling Setpoint Cooling temperature setpoint used for control in unoccupied mode.
Analog Output, 32 Unoccupied Heating Setpoint Heating temperature setpoint used for control in unoccupied mode.
Binary Input, 9 VAV Box Command Indicates whether VAV boxes should be in control or wide open.
